16 METER SELF PROPELLED ARTICULATING BOOM LIFT
PRODUCT CODE
GTBZ16AE
GTBZ16AE
BRAND
Dingli
Dingli
STICKERS
| Max.Working Height | 16.00m |
| Max.Platform Height | 14.00m |
| Max.Horizontal Reach | 7.15m |
| Max.Horizontal Reach | 7.89m |
| Overall Length(Stowed)(A) | 6.77m |
| Overall Length(Transport)(A1) | 5.15m |
| Overall Width(D) | 1.73m |
| Overall Height(C) | 2.00m |
| Platform Size | 1.45m×0.76m |
| Ground Clearance | 0.20m |
| Wheel Base(B) | 2.00m |
| S.W.L | 230kg |
| Max.Occupants | 2 |
| Turntable Tailswing | 0 |
| Turning Radius(Inside/Outside) | 2.08m/3.30m |
| Turret Rotation | 360°uncontinuous |
| Platform Rotation | ±90° |
| Jib Movement | +70°/-60° |
| Travel Speed(Stowed) | 6.1km/h |
| Travel Speed(Working) | ≤0.5km/h |
| Gradeability | 30% |
| Maximum Slope | 3° |
| Tyre | 17.6×6.75 |
| Batteries | 8×6V/420Ah |
| Integrated Charger | 48V/25A |
| Drive Motor | AC 48V/3.3kW |
| Lifting Motor | 48V/4.5kw |
| Hydraulic Tank | 30L |
| Gross Weight | 6700kg |
Standard equipment
● Proportional controls
● Manual electric pump
● Hour meter
● Tilt sensor
● 360° continuous turntable rotation
● Self-leveling platform
● Deadman
● Foam-filled Tyres
● 4×2 Drive
● Onboard diagnostic system
● All motion alarm
● Horm
● Flashing beacon
● Zero emission
● Manual electric pump
● Hour meter
● Tilt sensor
● 360° continuous turntable rotation
● Self-leveling platform
● Deadman
● Foam-filled Tyres
● 4×2 Drive
● Onboard diagnostic system
● All motion alarm
● Horm
● Flashing beacon
● Zero emission
Options
● Overload sensor with alarm
● AC power to platform
● Platform work lights
● Non-marking tyres
● AC power to platform
● Platform work lights
● Non-marking tyres
